Standard of Sintered Nd-Fe-B Magnetic Performance

Grade	Remanence Br (Min)		Coercivity Hcb (Min)		Intrinsic Coercivity Hcj (Min)		Max Energy (BH)max		Knee Point HK (Min)		HK/HCj (%)
Grade	KGs	T	KOe	KA/m	KOe	KA/m	MGOe	Kj/m³	KOe	KA/m	HK/HCj (%)
N30	10.8	1.08	10.0	796	12	960	28-31	223-247	11.4	912	95
N35	11.8	1.18	10.8	860	12	960	33-36	263-287	11.4	912	95
N40	12.6	1.26	10.8	860	12	960	38-41	302-326	11.4	912	95
N45	13.3	1.33	10.8	860	12	960	43-46	342-366	11.4	912	95
N50	13.9	1.39	10.5	836	12	960	47-51	374-406	11.4	912	95
35M	11.8	1.18	10.8	860	14	1114	33-36	263-287	13.3	1058	95
40M	12.6	1.26	11.4	910	14	1114	38-41	302-326	13.3	1058	95
45M	13.3	1.33	12.2	971	14	1114	43-46	342-366	13.3	1058	95
35H	11.8	1.18	10.9	868	17	1353	33-36	263-287	16.15	1285	95
40H	12.6	1.26	11.6	924	17	1353	38-41	302-326	16.15	1285	95
45H	13.3	1.33	12.5	995	17	1353	43-46	342-366	16.15	1285	95
35SH	11.8	1.18	10.9	868	20	1592	33-36	263-287	18	1433	90
40SH	12.6	1.26	11.5	912	20	1592	38-41	302-326	18	1433	90
35UH	11.8	1.18	10.6	845	25	1990	33-36	263-287	22.5	1791	90
40UH	12.6	1.26	11.5	916	25	1990	38-41	302-326	22.5	1791	90
35EH	11.8	1.18	11.1	883	30	2388	33-36	263-287	27	2149	90
40EH	12.6	1.26	11.9	947	30	2388	38-41	302-326	27	2149	90
35TH	11.8	1.18	10.6	845	35	2786	33-36	263-287	31.5	2507	90
